Replaces OEM part numbers: FBA000002
Associated Manufacturers
Description
Same size and efficiency as the Air King M-25's standard bag: 65% (MERV 11) fiberglass bag filter, 24" x 24" x 36", 8 pockets (RX part FBA000002). Air King ships the M-25 with a 24 x 24 x 36 65% 8-pocket bag behind a 24 x 24 x 4 pleated pre-filter. This bag matches it in size, efficiency and pocket count, with about 96 sq ft of fiberglass media for general shop dust. Air King's M-30, M-40, M-45 and M-70 series take 22"-deep bags in the same 24 x 24 face (65% version: SKU 50452), so check the depth of the bag you take out. Specifications: • Size: 24 x 24 x 36 in. • Efficiency: 65% (MERV 11) • Media: fiberglass, approx. 96 sq ft • Pockets: 8 • Temperature rating: 200°F • Stage: main filter Fits: • Air King M25 (the M-25HE takes a 15" 95% bag instead) For weld smoke and fine fume, the 95% (MERV 15) bag in this size is SKU 50459. Install with the pockets pointing downstream and hanging straight, without folds, behind the pre-filter, and replace it when your gauge reaches the change point or airflow drops. Price shown is per filter; sold in pairs (minimum order 2).
Specifications
Media Surface Footage (Sq') Media Surface Footage (Sq') The total surface area of the filter media, measured in square feet, which affects airflow capacity and dust-holding performance. | 96 |
Filter Efficiency (%) Filter Efficiency (%) The percentage of particles a filter can capture from the air, indicating how effective the filter is at removing contaminants. | 65 |
Media Type Media Type The material or composition of the filter media, which determines filtration efficiency, durability, and application suitability. | Fiberglass |
Temperature Rating (°F) Temperature Rating (°F) The maximum operating temperature the filter can safely withstand without degrading performance or structural integrity. | 200 |
Substitute For Substitute For Identifies alternative or equivalent part numbers that this filter can replace in compatible systems. | FBA000002 |
MERV MERV A standardized rating (Minimum Efficiency Reporting Value) that indicates how effectively a filter captures airborne particles, with higher values representing finer filtration. | 11 |
Filter Stage Filter Stage Where the filter sits in your collector: a pre-filter catches larger particles first, the main filter does most of the filtering, and an after-filter is the final stage. | Main |
Dimensions Dimensions The filter's size in inches (for media rolls, the length is in feet). Panel and bag filter sizes are nominal, so the actual filter can measure slightly smaller. | 24x24x36 |
