Replaces OEM part numbers: 7FJ9-5004
Associated Manufacturers
Description
Genuine Airflow Systems 7FJ9-5004 DOP filter: 95% DOP (MERV 16), 18" x 19" x 4", metal frame, for the MistPak MP14 mist collector. Airflow Systems lists the 7FJ9-5004 as the MP14's 95% DOP filter. The MP14 is built with a 2" aluminum mesh pre-filter and three MIST-PLUS main filters; the DOP filter is added after them with Airflow Systems' external DOP option (EXDOP), which holds one, or the Extended Life DOP-XL "A" frame, which holds two. As the after-filter stage, it catches the fine mist and smoke that get past the main filters. Specifications: • Part number: 7FJ9-5004 • Size: 18 x 19 x 4 in. • Efficiency: 95% DOP (MERV 16) • Frame: metal • Temperature rating: 200°F • Stage: after-filter Fits: • Airflow Systems MP14 (external DOP option: 1 per unit; DOP-XL: 2) Other MP14 filters on this site: the 7FA8-0006 aluminum mesh pre-filter (SKU 50762) and the MIST-PLUS main filters, 95% 2AF7-4001 (SKU 50802) or MIST-PLUS II 97% 2AF7-4000 (SKU 50806), three per unit. Keep the main filters changed on schedule to protect the DOP filter, and replace it when your gauge reaches the change point or airflow drops.
Specifications
Dimensions Dimensions The filter's size in inches (for media rolls, the length is in feet). Panel and bag filter sizes are nominal, so the actual filter can measure slightly smaller. | 18x19x4 |
Temperature Rating (°F) Temperature Rating (°F) The maximum operating temperature the filter can safely withstand without degrading performance or structural integrity. | 200 |
Substitute For Substitute For Identifies alternative or equivalent part numbers that this filter can replace in compatible systems. | 7FJ9-5004 |
Outer Shell Outer Shell The external layer or casing of the filter that provides structural support and protects the filter media during operation and handling. | Metal |
MERV MERV A standardized rating (Minimum Efficiency Reporting Value) that indicates how effectively a filter captures airborne particles, with higher values representing finer filtration. | 16 |
Media Type Media Type The material or composition of the filter media, which determines filtration efficiency, durability, and application suitability. | DOP |
Filter Stage Filter Stage Where the filter sits in your collector: a pre-filter catches larger particles first, the main filter does most of the filtering, and an after-filter is the final stage. | After |
Filter Efficiency (%) Filter Efficiency (%) The percentage of particles a filter can capture from the air, indicating how effective the filter is at removing contaminants. | 95 |
