Replacement For Filter 1 FLCA30CCLFOF Nano Cartridge Filter
Buying for a business? Purchase orders, invoicing and tax-exempt purchasing are available. Set up a business account
Replaces OEM part numbers: FLCA30CCLFOF
Associated Manufacturers
Description
Replacement for Filter 1 FLCA30CCLFOF (RX part FCA000017): flame-retardant nano cartridge filter. This cartridge replaces the FLCA30CCLFOF used in Filter 1 DC dust collectors. It measures 30" long x 12.75" OD x 8.275" ID, with one open end; the other end is closed with a center indent. Nano media puts a layer of fine fibers on the pleat surface, so fine particles such as weld fume, plasma and laser smoke and fine metal dust are caught on the surface, where pulse cleaning can knock them off. Specifications: • Size: 30 x 12.75 x 8.275 in. (1230) • Ends: open / closed, center indent • Media: nano, flame retardant, MERV 15, 230 sq ft • Outer support: expanded metal • Temperature rating: 180°F • Stage: main filter Fits: • Filter 1 DC dust collectors (FLCA30CCLFOF) • Filter 1 PFV-6 / PFV-8 Check your collector's manual for the number of cartridges. Replace them when pulse cleaning no longer brings the pressure drop back down.
Specifications
Dimensions Dimensions The filter's size in inches (for media rolls, the length is in feet). Panel and bag filter sizes are nominal, so the actual filter can measure slightly smaller. | 30x12.75x8.275 |
Temperature Rating (°F) Temperature Rating (°F) The maximum operating temperature the filter can safely withstand without degrading performance or structural integrity. | 180 |
Substitute For Substitute For Identifies alternative or equivalent part numbers that this filter can replace in compatible systems. | FLCA30CCLFOF |
Outer Shell Outer Shell The external layer or casing of the filter that provides structural support and protects the filter media during operation and handling. | Expanded Metal |
MERV MERV A standardized rating (Minimum Efficiency Reporting Value) that indicates how effectively a filter captures airborne particles, with higher values representing finer filtration. | 15 |
Media Type Media Type The material or composition of the filter media, which determines filtration efficiency, durability, and application suitability. | Nano |
Media Surface Footage (Sq') Media Surface Footage (Sq') The total surface area of the filter media, measured in square feet, which affects airflow capacity and dust-holding performance. | 230 |
Fire Retardant Fire Retardant Indicates whether the filter media or construction is treated to resist ignition and slow the spread of fire for improved safety. | Yes |
Filter Stage Filter Stage Where the filter sits in your collector: a pre-filter catches larger particles first, the main filter does most of the filtering, and an after-filter is the final stage. | Main |
Filter Size Filter Size The physical dimensions or nominal size of a filter, used to ensure proper fit and compatibility with the equipment. | 1230 |
Filter Ends Filter Ends The design and configuration of a filter’s end caps or closures, which determine how the filter is sealed and mounted in the system. | Open / Closed (O/C) |
