Replaces OEM part numbers: 7FB9-0114
Associated Manufacturers
Description
Genuine Airflow Systems 7FB9-0114 bag filter: 95% (MERV 15) short main bag for the Airflow Systems 2400 and 2400VOM. This 24" x 24" x 14" bag has 8 fiberglass pockets. In the dry 2400 it traps fine dust, smoke and fume; in the 2400VOM it catches the fine oil smoke and mist that get past the pre-filter. Specifications: • Part number: 7FB9-0114 • Size: 24 x 24 x 14 in. • Efficiency: 95% (MERV 15) • Pockets: 8 • Media: fiberglass • Temperature rating: 200°F • Stage: main filter Fits: • Airflow Systems 2400 • Airflow Systems 2400VOM Other stages for these units: the 7FA8-0101 aluminum mesh pre-filter (SKU 50760), and the 7FJ9-5112 DOP (SKU 51031) or 7FJ9-9113 HEPA (SKU 51026) after-filter. Install with the pockets pointing downstream, behind the pre-filter; check your manual for the number of bags. Replace when your gauge reaches the change point or when mist or smoke shows at the discharge. Sold in packs of 2.
Specifications
Dimensions Dimensions The filter's size in inches (for media rolls, the length is in feet). Panel and bag filter sizes are nominal, so the actual filter can measure slightly smaller. | 24x24x14 |
Temperature Rating (°F) Temperature Rating (°F) The maximum operating temperature the filter can safely withstand without degrading performance or structural integrity. | 200 |
Substitute For Substitute For Identifies alternative or equivalent part numbers that this filter can replace in compatible systems. | 7FB9-0114 |
MERV MERV A standardized rating (Minimum Efficiency Reporting Value) that indicates how effectively a filter captures airborne particles, with higher values representing finer filtration. | 15 |
Media Type Media Type The material or composition of the filter media, which determines filtration efficiency, durability, and application suitability. | Fiberglass |
Media Surface Footage (Sq') Media Surface Footage (Sq') The total surface area of the filter media, measured in square feet, which affects airflow capacity and dust-holding performance. | 87 |
Filter Stage Filter Stage Where the filter sits in your collector: a pre-filter catches larger particles first, the main filter does most of the filtering, and an after-filter is the final stage. | Main |
Filter Efficiency (%) Filter Efficiency (%) The percentage of particles a filter can capture from the air, indicating how effective the filter is at removing contaminants. | 95 |
