Replacement for Plymovent 6815-1011 (0000100356) Nano FR Cartridge Filter
Buying for a business? Purchase orders, invoicing and tax-exempt purchasing are available. Set up a business account
Replaces OEM part numbers: 6815-1011
Associated Manufacturers
Description
Replacement for Plymovent 0000100356 (formerly 6815-1011) in fire-retardant nanofiber media: MERV 15, 238 sq ft. This cartridge fits Plymovent MultiDust Bank (MDB) BM series and Plymovent B series collectors that take the 0000100356. It is open at the top and closed at the bottom with a bolt hole, with outer support bands and a D-ring. Nanofiber media puts a layer of fine fibers on the pleat surface, so fine weld fume stays on the surface, where pulse cleaning can release it. Specifications: • Size: about 12.8" OD x 8.5" ID x 30" long (1330) • Ends: open top / closed bottom with bolt hole • Media: fire-retardant nanofiber, MERV 15, 238 sq ft • Outer support: bands • Handle: D-ring • Temperature rating: 180°F • Stage: main filter Fits: • Plymovent MultiDust Bank (MDB) BM series 2 / 4 / 8 / 10 / 12 • Plymovent B series 6 / 8 / 10 / 12 / 16 / 20 Other cartridges for the same Plymovent number: SKU 50555 (nanofiber, MERV 14, 230 sq ft, expanded-metal liner) and SKU 50556 (spunbond polyester, MERV 11, 150 sq ft, rated to 275°F). Check your collector's manual for the cartridge count. Replace when pulse cleaning no longer brings the pressure drop back down.
Specifications
Temperature Rating (°F) Temperature Rating (°F) The maximum operating temperature the filter can safely withstand without degrading performance or structural integrity. | 180 |
Substitute For Substitute For Identifies alternative or equivalent part numbers that this filter can replace in compatible systems. | 6815-1011 |
Outer Shell Outer Shell The external layer or casing of the filter that provides structural support and protects the filter media during operation and handling. | Bands |
MERV MERV A standardized rating (Minimum Efficiency Reporting Value) that indicates how effectively a filter captures airborne particles, with higher values representing finer filtration. | 15 |
Media Type Media Type The material or composition of the filter media, which determines filtration efficiency, durability, and application suitability. | Nano |
Media Surface Footage (Sq') Media Surface Footage (Sq') The total surface area of the filter media, measured in square feet, which affects airflow capacity and dust-holding performance. | 238 |
Fire Retardant Fire Retardant Indicates whether the filter media or construction is treated to resist ignition and slow the spread of fire for improved safety. | Yes |
Filter Stage Filter Stage Where the filter sits in your collector: a pre-filter catches larger particles first, the main filter does most of the filtering, and an after-filter is the final stage. | Main |
Filter Size Filter Size The physical dimensions or nominal size of a filter, used to ensure proper fit and compatibility with the equipment. | 1330 |
Filter Ends Filter Ends The design and configuration of a filter’s end caps or closures, which determine how the filter is sealed and mounted in the system. | Open / Closed with Bolt (O/CB) |
