Replacement for Plymovent MDB/BM Cartridge Filter 0000100356 (6815-1011)
Buying for a business? Purchase orders, invoicing and tax-exempt purchasing are available. Set up a business account
Replaces OEM part numbers: 0000100356, 6815-1011
Associated Manufacturers
Description
Replacement for Plymovent 0000100356 (formerly 6815-1011): fire-retardant spunbond polyester cartridge filter, MERV 11, 150 sq ft, rated to 275°F. This cartridge fits Plymovent MultiDust Bank (MDB) BM series collectors. It is open at the top and closed at the bottom with a bolt hole, with an expanded-metal outer liner and a D-ring. Specifications: • Size: 12.75" OD x 8.5" ID x 29" long (1229) • Ends: open top / closed bottom with bolt hole • Media: fire-retardant spunbond polyester, MERV 11, 150 sq ft • Outer support: expanded metal • Handle: D-ring • Temperature rating: 275°F • Stage: main filter Fits: • Plymovent MultiDust Bank (MDB) BM series 2 / 4 / 8 / 10 / 12 For finer fume, the same Plymovent number is also covered in fire-retardant nanofiber media: SKU 50555 (MERV 14, 230 sq ft) and SKU 50558 (MERV 15, 238 sq ft). Check your collector's manual for the cartridge count. Replace when pulse cleaning no longer brings the pressure drop back down. In-stock orders placed by noon CT ship the same business day. Not sure it's the right one? Measure your old filter (OD, ID, length and which ends are open) or send us its part number or a photo through the chat button, and we'll confirm the match before you order. 30-day returns.
Specifications
Dimensions Dimensions The filter's size in inches (for media rolls, the length is in feet). Panel and bag filter sizes are nominal, so the actual filter can measure slightly smaller. | 29x12.75x8.5 |
Temperature Rating (°F) Temperature Rating (°F) The maximum operating temperature the filter can safely withstand without degrading performance or structural integrity. | 275 |
Substitute For Substitute For Identifies alternative or equivalent part numbers that this filter can replace in compatible systems. | 0000100356, 6815-1011 |
Outer Shell Outer Shell The external layer or casing of the filter that provides structural support and protects the filter media during operation and handling. | Expanded Metal |
MERV MERV A standardized rating (Minimum Efficiency Reporting Value) that indicates how effectively a filter captures airborne particles, with higher values representing finer filtration. | 11 |
Media Type Media Type The material or composition of the filter media, which determines filtration efficiency, durability, and application suitability. | Spunbond Poly |
Media Surface Footage (Sq') Media Surface Footage (Sq') The total surface area of the filter media, measured in square feet, which affects airflow capacity and dust-holding performance. | 150 |
Fire Retardant Fire Retardant Indicates whether the filter media or construction is treated to resist ignition and slow the spread of fire for improved safety. | Yes |
Filter Stage Filter Stage Where the filter sits in your collector: a pre-filter catches larger particles first, the main filter does most of the filtering, and an after-filter is the final stage. | Main |
Filter Size Filter Size The physical dimensions or nominal size of a filter, used to ensure proper fit and compatibility with the equipment. | 1229 |
Filter Ends Filter Ends The design and configuration of a filter’s end caps or closures, which determine how the filter is sealed and mounted in the system. | Open / Closed with Bolt (O/CB) |
