1612 Cartridge Filter, 80/20 Media, MERV 11 (Same Size as 7FR0-2016)
Associated Manufacturers
Description
1612 cartridge filter in fire-retardant 80/20 media, MERV 11 (RX part FCA000001). Same size as the Airflow Systems 7FR0-2016 (also written 7FRO-2016). It has the 7FR0-2016's size and end layout: 16" OD x 11.5" long, open on one end and closed on the other, with a bolt hole. The media is different: the genuine 7FR0-2016 uses Airflow Systems' CLEAN-2 media, while this cartridge uses 80/20, which works well on larger, dry particulate such as wood dust and is also used for weld fume. Specifications: • Size: 16" OD x 9.625" ID x 11.5" long (1612) • Ends: open / closed, with bolt hole • Media: 80/20, fire retardant, MERV 11, 140 sq ft • Outer support: expanded metal • Temperature rating: 180°F • Stage: main filter Fits (units that take the 7FR0-2016 size): • Airflow Systems PowerBooth • Airflow Systems DT-800 • Airflow Systems DT-3000 (older style) • Airflow Systems PC-1, PC-2, DC-1, DC-2 (older style) Need finer capture? The same 1612 size in flame-retardant UltraLife media (MERV 15) is SKU 50697, an OEM-equivalent replacement for 7FR0-2016. Seat the open end on the tube sheet and secure the cartridge through the closed-end bolt hole with the unit's retaining hardware so the gasket compresses evenly; check your manual for the cartridge count. Replace it when filter cleaning no longer brings the pressure drop back down or airflow drops off. In-stock orders placed by noon CT ship the same business day. Not sure it's the right one? Measure your old filter (OD, ID, length and which ends are open) or send us its part number or a photo through the chat button, and we'll confirm the match before you order. 30-day returns.
Specifications
Filter Ends Filter Ends The design and configuration of a filter’s end caps or closures, which determine how the filter is sealed and mounted in the system. | Open / Closed (O/C) |
Filter Size Filter Size The physical dimensions or nominal size of a filter, used to ensure proper fit and compatibility with the equipment. | 1612 |
Dimensions Dimensions The filter's size in inches (for media rolls, the length is in feet). Panel and bag filter sizes are nominal, so the actual filter can measure slightly smaller. | 11.5x16x9.625 |
Media Type Media Type The material or composition of the filter media, which determines filtration efficiency, durability, and application suitability. | 80/20 |
Fire Retardant Fire Retardant Indicates whether the filter media or construction is treated to resist ignition and slow the spread of fire for improved safety. | Yes |
Media Surface Footage (Sq') Media Surface Footage (Sq') The total surface area of the filter media, measured in square feet, which affects airflow capacity and dust-holding performance. | 140 |
Temperature Rating (°F) Temperature Rating (°F) The maximum operating temperature the filter can safely withstand without degrading performance or structural integrity. | 180 |
Filter Stage Filter Stage Where the filter sits in your collector: a pre-filter catches larger particles first, the main filter does most of the filtering, and an after-filter is the final stage. | Main |
MERV MERV A standardized rating (Minimum Efficiency Reporting Value) that indicates how effectively a filter captures airborne particles, with higher values representing finer filtration. | 11 |
Outer Shell Outer Shell The external layer or casing of the filter that provides structural support and protects the filter media during operation and handling. | Expanded Metal |
