Replaces OEM part numbers: 7FR0-2912
Associated Manufacturers
Description
Genuine Airflow Systems 7FR0-2912 cartridge filter (also written 7FRO-2912). The 7FR0-2912 is the CLEAN-2 cartridge Airflow Systems uses in its PC collectors and its V2 / V4 portable high-vacuum collectors. It is open on one end and closed on the other, with a gasket on each end. V2 / V4 units pull dust at high velocity through hoses, often straight from the tool, and the MERV 14 CLEAN-2 media helps capture the fine dust those tools produce. Specifications: • Part number: 7FR0-2912 • Size: 11.5 x 12 x 9.625 in. (1212) • Ends: open / closed, gasket each end • Media: CLEAN-2, MERV 14, 107 sq ft • Pleat support: glue bead • Temperature rating: 180°F • Stage: main filter Fits: • Airflow Systems PC • Airflow Systems V2 / V4 Seat the open end on the tube sheet and secure the closed end with the unit's retaining hardware so both gaskets compress evenly. Replace the cartridge when cleaning no longer brings the pressure drop back down or suction at the tool falls off.
Specifications
Dimensions Dimensions The filter's size in inches (for media rolls, the length is in feet). Panel and bag filter sizes are nominal, so the actual filter can measure slightly smaller. | 11.5x12x9.625 |
Temperature Rating (°F) Temperature Rating (°F) The maximum operating temperature the filter can safely withstand without degrading performance or structural integrity. | 180 |
Substitute For Substitute For Identifies alternative or equivalent part numbers that this filter can replace in compatible systems. | 7FR0-2912 |
Outer Shell Outer Shell The external layer or casing of the filter that provides structural support and protects the filter media during operation and handling. | Glue Bead |
MERV MERV A standardized rating (Minimum Efficiency Reporting Value) that indicates how effectively a filter captures airborne particles, with higher values representing finer filtration. | 14 |
Media Type Media Type The material or composition of the filter media, which determines filtration efficiency, durability, and application suitability. | CLEAN-2 |
Media Surface Footage (Sq') Media Surface Footage (Sq') The total surface area of the filter media, measured in square feet, which affects airflow capacity and dust-holding performance. | 107 |
Filter Stage Filter Stage Where the filter sits in your collector: a pre-filter catches larger particles first, the main filter does most of the filtering, and an after-filter is the final stage. | Main |
Filter Size Filter Size The physical dimensions or nominal size of a filter, used to ensure proper fit and compatibility with the equipment. | 1212 |
Filter Ends Filter Ends The design and configuration of a filter’s end caps or closures, which determine how the filter is sealed and mounted in the system. | Open / Closed (O/C) |
